908BL-B84
908BL Special Type Double Wall
BasicLength：270/300/350/400/450/500/550mm
Describe：
Nominal lengths: 270/300/350/400/450/500/550mm
Drawer side height: 84mm
Full
extension
Easy assembling and dismantling
Integrated 3D front adjustment, quick
installation and precise alignment
Loading: standard version up to 35kg (75lb),
optional heavy duty version 50kg (110 lb)
Standard packing: 1 set per carton, optional
bulk packing
Drawer material: steel with coating, options in stainless steel, and
Aluminium
1.Smooth sliding and soft damping bring to effortiess
closing
2.Modern design with large internal drawer spce, and compatible
drillings
3.Quick installation and dismantling makes life easy
4.Standard 35kg
version is certified 60,000 life cycle: High durability options available
5.Optional
new design with drawer tightly connected to slide for high safety
requirement
6.Compatible drillings positions
Applications
Kitchen
cabinet & furniture, living room furniture & bathroom furniture
